Tension / Compression Load Cell
TU-PGRH☐☐N/KN-G
RoHS
Tension / compression Load cell. It is a product using a high impedance circuit.Minimized temperature drift due to self-heating.
Made in Japan
- Features
- High precision · Sealed structure · High stability
Specifications
| Model | Unit | Rated Capacity (R.C.) | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TU-PGRH☐☐N/KN-G | N | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 | 20 | 50 | 100 | 200 | 500 | |
| kN | 1 | 2 | 3 | 5 | 10 | 20 | 30 | 50 | 100 | 200 | 300 | 500 | 1000 | |
| Rated Capacity (R.C.) | Natural Frequency | Weight (g) |
|---|---|---|
| 200N | 1.0kHz | 0.4kg |
| 500N | 1.6kHz | 0.4kg |
| 1kN | 2.2kHz | 0.4kg |
| 2kN | 2.1kHz | 1.3kg |
| 3kN | - | 1.3kg |
| 5kN | 3.4kHz | 1.3kg |
| Model | TU-PGRH☐☐N/KN-G |
|---|---|
| Rated Capacity(R.C) | 150%R.C. |
| Rated Output (R.O.) | 2mV/V ±0.3% |
| Linearity | 0.015%R.O. |
| Hysteresis | 0.020%R.O. |
| Repeatability | 0.015%R.O. |
| Safe Excitation Voltage | 10V |
| Input Terminal Resistance | 1050Ω±10Ω |
| Output Terminal Resistance | 1050Ω±10Ω |
| Insulation Resistance | 1000MΩ or more (DC50V) |
| Compensated Temperature Range | -10℃ - 60℃ |
| Permissible Temperature Range | -30℃ - 80℃ |
| Temperature Effect on Zero Balance | 0.020% R.O./10℃ |
| Temperature Effect on Output | 0.025% R.O./10℃ |
| Cable | φ6mm 4-core shielded, 5m direct connection with bare lead wires |
| Body material | Steel (coated surface) |
Outline Dimensions
