Pressure (Flash Diagram)
TP-BR(T)
TEDS RoHS
Specifications
| Rated Capacity (R.C.) | Natural Frequency | Weight (g) |
|---|---|---|
| 1MPa | 26kHz | 120g |
| 2MPa | 37kHz | |
| 5MPa | 56kHz | |
| 10MPa | 80kHz | |
| 20MPa | 100kHz | |
| 50MPa | 170kHz |
| Model | TP-BR(T) |
|---|---|
| Safe Overload Rating | 150%R.C. |
| Rated Output (R.O.) | 1.5mV/V 1mV/V (500KPa) |
| Linearity | 0.5%R.O. |
| Hysteresis | 0.5%R.O. |
| Repeatability | 0.5%R.O. |
| Safe Excitation Voltage | 6V |
| Input Terminal Resistance | 350±3.5Ω |
| Output Terminal Resistance | 350±3.5Ω |
| Insulation Resistance | 1000MΩ (DC50V) |
| Compensated Temperature Range | -10℃ - 60℃ |
| Permissible Temperature Range | -10℃ - 60℃ |
| Temperature Effect on Zero Balance | 0.8%R.O./10℃ |
| Temperature Effect on Output | 0.8%R.C./10℃ |
| Attachment screw | G3/8 (PF3/8) |
| Body material | Stainless steel |
| Cable | φ6mm 4-core shieleded cable 0.3m direct connection with NDI7J (PRC03-32A10-7F) |
| TEDS | Built-in connector |
| Environmental compliance | RoHS 10 |
Outline Dimensions
